Product name: Wire Rope Clip
Standard: JIS Type B-2809
Material: 45#
Specification: M6- M25
Surface treatment: Galvanized,Hot Dip Galvanized
Origin: Qingdao, Shandong, China
Contact us ：huang@qdxqx.com
| Nominal Size | Dimensions(mm) | |||||
| (mm) | A | B | C | D | E | G |
| 6 | 14 | 20 | 29 | 35 | 17 | 24 |
| 8 | 18 | 20 | 36 | 40 | 19 | 31 |
| 10 | 22 | 28 | 45 | 50 | 23 | 35 |
| 12 | 26 | 35 | 51 | 60 | 28 | 39 |
| 14 | 28 | 40 | 53 | 65 | 32 | 45 |
| 16 | 32 | 45 | 60 | 75 | 36 | 48 |
| 18 | 34 | 50 | 62 | 80 | 38 | 53 |
| 20-22 | 44 | 60 | 78 | 100 | 45 | 62 |
| 24-25 | 48 | 65 | 86 | 110 | 49 | 68 |
