| Product: | US Type Turnbuckles |
| Material： | Carbon steel, 45# |
| Finish： | Hot Dipped Galvanized, Environmental Galv ,Dacromet |
| Technology： | Drop forged |
| Size： | From 1/4'' *4'' to 2 3/4'' * 24'' |
| Packing： | by customer requirements. |
| other： | Special specifications and marks can be made according to customers requirements; |
| Email: | huang@qdxqx.com |
 | Size （Diameter× Take-Up) | Acerage Ocerall Length with Ends in Closed Position | Approx.Weight Each(1bs) | Work Load Limit | |||||
| Pounds | |||||||||
| Eyes | Jaw& | Jaw& | Stub | Badies | Hook& | Eye&Eye | |||
| and/or | Hook Hook | Jaw&Eye | |||||||
| Hooks | Eye | Jaw | End | Only | Jaw&Jaw | ||||
| &Eye | Stub End | ||||||||
| 1/4"x4" | 81/4 | 3 | 3 | 4 | 0.29 | 0.17 | 400 | 500 | |
| 5/16"x41/2" | 91/16 | 0.5 | 35 | 0.58 | 0.46 | 0.25 | 700 | 800 | |
| 3/8"x6" | 117/8 | 0.75 | 82 | 0.93 | 0.75 | 0.3 | 1.000 | 12.000 | |
| 1/2"x6" | 135/16 | 1.5 | 1.62 | 1.68 | 1.36 | 0.55 | 1.500 | 2.200 | |
| 1/2"x9" | 165/16 | 1.75 | 1.82 | 1.85 | 1.69 | 0.74 | 1.500 | 2.200 | |
| 1/2"x12" | 195/16 | 2.18 | 2.19 | 2.2 | 2 | 0.93 | 1.500 | 2.200 | |
| 5/8"x6" | 151/2 | 2.63 | 2.59 | 2.82 | 2.15 | 0.91 | 2.250 | 3.500 | |
| 5/8"x9" | 181/2 | 3 | 3.01 | 3.25 | 2.7 | 1.2 | 2.250 | 3.500 | |
| 5/8"x12" | 211/2 | 3.25 | 3.5 | 3.75 | 3.22 | 1.5 | 2.250 | 3.500 | |
| 3/4"x6" | 17 | 3.75 | 4.25 | 4.68 | 3.25 | 1.3 | 3.000 | 5.200 | |
| 3/4"x9" | 20 | 4.5 | 5 | 5.38 | 4 | 1.7 | 3.000 | 5.200 | |
| 3/4"x12" | 23 | 5.75 | 5.75 | 6.12 | 4.65 | 2.12 | 3.000 | 5.200 | |
| 3/4"x18" | 29 | 7 | 7.25 | 7.25 | 6.12 | 2.93 | 3.000 | 5.200 | |
| 7/8"x6" | 18 | -- | -- | -- | 4.75 | 2 | -- | 7.200 | |
| 7/8"x12" | 245/8 | 8.38 | 8.88 | 9.36 | 6.67 | 3 | 4.000 | 7.200 | |
| 7/8"x18" | 305/8 | 10.25 | 10.6 | 11.44 | 8.75 | 4.12 | 4.000 | 7.200 | |
| 1"x6" | 205/8 | -- | -- | -- | 6.41 | 2.5 | -- | 10.000 | |
| 1"x12" | 265/8 | 11.25 | 12 | 12.88 | 8.9 | 3.86 | 5.000 | 10.000 | |
| 1"x18" | 325/8 | 14 | 14.75 | 16.1 | 11.7 | 5.5 | 5.000 | 10.000 | |
| 1"x24" | 385/8 | 17 | 17.75 | 18.6 | 14.3 | 7 | 5.000 | 10.000 | |
| 11/4"x6" | 20 | -- | -- | -- | 10.4 | 4 | -- | 15.200 | |
| 11/4"x12" | 297/8 | 19 | 21.2 | 23.6 | 14.2 | 5.93 | -- | 15.200 | |
| 11/4"x18" | 357/8 | 24.1 | 26 | 26.6 | 18 | 8 | - | 15.200 | |
| 11/4"x24" | 417/8 | 25 | 28.7 | 31.2 | 21.8 | 10 | - | 15.200 | |
| 11/2"x6" | 221/2 | -- | - | -- | 15.4 | 5.8 | - | 21.400 | |
| 11/2"x12" | 323/8 | 27 | 31.1 | 35.5 | 20.5 | 8.4 | - | 21.400 | |
| 11/2"x18" | 383/8 | 31.2 | 36.4 | 40.7 | 26.2 | 11.5 | - | 21.400 | |
| 11/2"x24" | 443/8 | 38.2 | 44.2 | 47.6 | 31.4 | 14.1 | - | 21.400 | |
| 13/4"x16" | - | -- | - | -- | 22.7 | 8.75 | - | 28.000 | |
| 134”x18” | 413/4 | 45 | 48.8 | 52.4 | - | - | - | 28.000 | |
Qingdao Xinquanxi Metal Products Co., Ltd. was established in 2001 (formerly known as Qingdao Quanxi Rigging Hardware Co., LTD.), located in Wangyanzhuang North Village, Lancun Town, Jimo District, Qingdao city. In the early stage of establishment, the company mainly engaged in the production and sales of JIS turnbuckles and forging shackle, and successfully entered the Japanese market with high quality products and established the foreign trade Department. With the continuous development of the company's business, in September 2019, it merged with Qingdao Ruihongjie Industry and Trade Co., LTD., and changed the company name to Qingdao Xinquanxi Metal Products Co., LTD. At the same time, the business scope has gradually expanded, the main production and operation of rigging, wire rope connection parts, precision machining, Pole line hardware, Marine and automotive connection parts, all kinds of forging, sheet metal, stamping, casting and other products.
Main products:
Rigging: turnbuckle (Jis open body, 1480 forging turnbuckle, US type forging turnbuckle,Rigging Screw), forging shackle, eye bolt and eye nut, forged hook, various sets of rings, D ring, master ring, snap hook,Pulley Block, etc.;
Corner code, expansion bolt, seismic support, guardrail and other building materials.
Casting pipes, manhole covers, road piles, container buttons, anchors, all kinds of breeding equipment and other casting products.
